Haptic feedback actuator

Haptic feedback actuatorModel：HM0013-000

Piezo Haptic Actuator is an operational interaction sensor. The function, scene or application set in the device will be waken up by touching or pressing with a liittle force. Short term press and long term press will be able to customize different gestures and wake up functions or applications.

Request a sample

Features

- High sensitivity and stable performance

- Low power consumption

- Better dust/ water proof

Specifications

Item	Specifications
Static Capacitance	121±15% nf
Loss	<4%
Length	25±0.15 mm
Width	4.2±0.05 mm
Thickness	1.05±0.1 mm
Displacement	23+5 μm
Operating Voltage	-10~52 V

Applications

- Display touch panel

- Car central control screen

- Switch

- Interior decoration

- Touch screen of various household appliances
